A - Hub Center To Flange Center, Non-Drive Side (mm): 36.9
B - Hub Center To Flange Center, Drive Side (mm): 22.47
C - Axle Width (mm): 148
Spoke Hole Circle Diameter, Drive Side (mm): 50.0
Spoke Hole Circle Diameter, Non-Drive Side (mm): 42.0
Spoke Hole Counts Available: 24
Specs
Weight: 13.5 oz / 383 g
Dimensions - Approximate for Shipping: 9.5 × 4.5 × 4 in
Hub Type: Rear
Axle Width - mm: 148
Axle Diameter - mm: 12
Spoke Count: 24
Attach Style: Thru-bolt
Hub Shell Style: Solid
Disc Brake Rotor Mount: Shimano Center Lock
Driver Style: Shimano Hyperglide 11 Speed
Spoke Tension - Max kgf: 120
Product Line: Vesper
