A - Hub Center To Flange Center, Non-Drive Side (mm): 21.8
B - Hub Center To Flange Center, Drive Side (mm): 37.4
C - Axle Width (mm): 110
Spoke Hole Circle Diameter, Drive Side (mm): 42.0
Spoke Hole Circle Diameter, Non-Drive Side (mm): 57.0
Spoke Hole Counts Available: 24
Specs
Weight: 6.0 oz / 170 g
Dimensions - Approximate for Shipping: 9.5 × 4.5 × 4 in
Hub Type: Front
Axle Width - mm: 110
Axle Diameter - mm: 20
Spoke Count: 24
Attach Style: Thru-bolt
Hub Shell Style: Solid
Disc Brake Rotor Mount: ISO 6-Bolt Flange
Spoke Tension - Max kgf: 120
Product Line: Vesper
