A - Hub Center To Flange Center, Non-Drive Side (mm): 32.65
B - Hub Center To Flange Center, Drive Side (mm): 19.47
C - Axle Width (mm): 135
Spoke Hole Circle Diameter, Drive Side (mm): 60.0
Spoke Hole Circle Diameter, Non-Drive Side (mm): 60.0
Spoke Hole Counts Available: 32
Specs
Weight: 14.4 oz / 408 g
Dimensions - Approximate for Shipping: 9.5 × 4.5 × 4 in
Hub Type: Rear
Axle Width - mm: 135
Axle Diameter - mm: 12
Spoke Count: 32
Attach Style: Thru-bolt
Hub Shell Style: Solid
Disc Brake Rotor Mount: ISO 6-Bolt Flange
Driver Style: Shimano Hyperglide 11 Speed
Spoke Tension - Max kgf: 120
Product Line: Vesper
