The 602 ERGOLUX® active 2.0, the trekking and touring saddle for medium to long distance riding. Compared to the former performance ERGOWAVE® models, the 602 ERGOLUX® 2.0 active offers greater padding volume which makes for softer feeling foam. The dual waves make the supporting surface significantly larger than before, keeping the sit bones from sinking less deeply into the sitting area. As a result, the Ergolux® does not have the disadvantages that normally come with softer foam.
The first level accommodates the rear part of the sit bones offering perfect support for improved force transmission onto the pedal. The second level ideally accommodates the unburdened ischial rami, thereby ensuring the best-possible pressure distribution. Due to the saddle nose sitting lower, the perineal and front area of the pubic bone and pubic arch have more free space.
Thanks to the proven SQlab active system which allows the saddle to follow the pedalling movements of the rider, comfort is increased, less strain is placed on the inter- vertebral discs and pressure on the sit bones is further reduced. Thanks to the proven SQlab active system which allows the saddle to follow the pedaling movements of the rider, comfort is increased, less strain is placed on the inter- vertebral discs and pressure on the sitbones is further reduced. The flex and active movement can be adjusted to the body weight with the comfort sticks in the active dampener.
Available in saddle widths 14, 15, 16 & 17 cm.
ARTICLE NUMBER(S): 2427 / 2428 / 2429 / 2430
AREA OF USE/BICYCLE TYPE: TREKKING
WIEGHT(S) IN G: APPROX. 440 / 443 / 454 / 468
ACTIVE TECHNOLOGY: YES - COMFORT
MOUNTING HEIGHT IN MM: APPROX. 78
SIZE(S) IN CM (EFFECTIVE SADDLE WIDTH): 14 / 15 / 16 / 17
LENGTH IN MM: APPROX. 280
MATERIAL RAILS: CRMO (SOLID)
MATERIAL BASE: POLYPROPYLENE COMPOUND (PP)
MATERIAL PADDING: LIGHT FOAM
MATERIAL COVER: MICROFIBRE
HARDNESS IN SQ-SHORE: 45
RELIEF OF PERINEAL AREA IN %: 70
MAXIMUM LOAD IN KG: 130
MAXIMUM TORQUE IN NM: 18
E-BIKE READY: YES
DIN / ASTM CATEGORIES: 2
602 ERGOLUX ACTIVE 2.0
Did you already measure your sitbones?
A prerequisite for maximum comfort and relief is the coordinated saddle width, so that it is guaranteed that your seat bones lie completely on the saddle. This is the only way to properly relieve the sensitive perineal area in men and the usually lower pubic arch in women.
"Once you get used to the stepped shape, the 602 with its firm padding and Active system provides the very best seating comfort. Loads the sit bones, relieves the perineum like no other."
aktiv Radfahren 03/2020
The raised rear results in more grip toward the rear and provides more efficient force transfer.
Comfortable Sitting Position
The wave-shaped elevation of the ERGOLUX® that extends frontward has a shape that fits perfectly to most bulbous ishial branches. The enlarged, less intermittent support surface provides optimal pressure distribution inside the ischial branches.
Lower saddle nose
The lower-lying saddle nose accordingly presses less on sensitive positions. Equally so for both men and women.
SQlab active system comfort
The SQlab technology relieves strain on intervertebral discs and sit bones. The active movement can be adjusted via two comfort sticks.
Low and flat
The flat saddle nose has a slight curvature which provides maximum contact area providing and associated reduced pressure. This shape provides a narrow saddle nose which minimizes chafing on the inside of the thighs while pedaling.
