SQLab Saddle, 6OX, Trail, Active, Ti/S-Tube,

SKU: 701-6201
$179.99
Excl. tax

The e-bike saddle 6OX combines the advantages of the successful saddle models ERGOWAVE® and ERGOLUX®. As part of the product development, the shape of the saddle was adapted and perfected for the special use on the E-MTB as well as for the Gravity Bike...

The rating of this product is 0 out of 5

(0)
On backorder

The e-bike saddle 6OX combines the advantages of the successful saddle models ERGOWAVE® and ERGOLUX®. As part of the product development, the shape of the saddle was adapted and perfected for the special use on the E-MTB as well as for the Gravity Bike.

The wave shaped 6OX profile which contours from the rear to the front offers a perfect form-fit shape for most sit bones. The raised back section provides more rearward support and ensures efficient power transmission. The grip material on the raised back provides additional support to the rear. In addition, the saddle cover is robust, especially at the edges.

The level and lowered saddle nose applies less pressure to the sensitive areas of men and women alike. For an even better pressure relief, especially on long technical climbs, the saddle nose of the 6OX became a little bit wider, but just as flat and with largest possible surface area. The padding was designed for the specific needs on the E-MTB with perfect dampening properties for rough off-road terrain.

Due to these modifications, the 6OX is the ideal saddle for long and steep climbs on the E-MTB and at the same time, even on bikes without an engine, it provides an optimum relief. The wave shaped 6OX profile which contours from the rear to the front offers a perfect form-fit shape for most sit bones.

The SQlab active-saddle technology lets the saddle follow the pedalling motion as comfort increases, the vertebral discs are mobilized and pressure on the sit bones is minimised. The correct width saddle is a prerequisite for maximum performance.


TECHNICAL SPECIFICATIONS

ARTICLE NUMBER(S): 1791 / 1792 / 1793 / 2142
AREA OF USE / BICYCLE TYPE: MTB GRAVITY & E-PERFORMANCE
SITTING POSITION(S): MODERATE (+2 CM) / BEND (+3 CM)
WEIGHT(S) IN G: APPROX. 272 / 294 / 304 / 322
ACTIVE TECHNOLOGY: YES - SPORT
MOUNTING HEIGHT IN MM: APPROX. 49
SIZE(S) IN CM (EFFECTIVE SADDLE WIDTH): 13 / 14 / 15 / 16
LENGTH IN MM: APPROX. 280
MATERIAL RAILS: S-TUBE (LIGHT METAL ALLOY - HOLLOW)
MATERIAL BASE: GLASS FIBRE REINFORCED POLYAMIDE COMPOUND (PA12 + GF)
MATERIAL PADDING: SUPERLIGHT FOAM
MATERIAL COVER: MICROFIBRE
HARDNESS IN SQ-SHORE: 55
RELIEF OF PERINEAL AREA IN %: 72
MAXIMUM LOAD IN KG: 110
MAXIMUM TORQUE IN NM: 18
E-BIKE READY: YES
DIN / ASTM CATEGORIES: 5
GENDER: UNISEX
